PTFE polyester mesh fabric , PTFE polyester mesh fabric for conveyor belt / griddling cloth, made by PTFE coated

10rolls
MOQ
negotiation
価格
PTFE polyester mesh fabric , PTFE polyester mesh fabric for conveyor belt / griddling cloth, made by PTFE coated
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
材料: PTFE+glassfiberかケブラー
色: 、黒い茶色、青い
共同: 丸みがある接合箇所、螺線形およびクラッパー
温度: -60 | +360°C
メッシュ: 0.5x1、1x1、2x2.5、4x4、6x6、10x10mm
幅: 最高3.8m
ハイライト:

ptfe conveyor belt

,

teflon mesh conveyor belt

基本情報
起源の場所: 中国
ブランド名: 3A Rubber
証明: ROHS/FCC/SGS
モデル番号: 3A3008
お支払配送条件
パッケージの詳細: カートンで詰められる
受渡し時間: 10 仕事日はの後のあなたの支払を受け取りました
支払条件: T ・ T、L/C、Paypal、ウェスタン ・ ユニオン
供給の能力: 1 ヶ月あたりの 10000kgs
製品の説明

PTFEは網ベルトを開けます

コンベヤー ベルト/PTFEのテフロンによってなされたグリドルで焼く布はガラス繊維によって補強された生地の網に塗りました

私達は質ガラス、ケブラーおよびいろいろな網サイズの開いた網を編むためにnomexヤーンを選び次にDu Pont最もよい私達のベルトの質を約束するPTFEの乳剤に塗りました。

特性:

容易なlの滑らかな表面はきれいになります

再使用可能な非lの

lの化学抵抗

特性を絶縁するl

lの熱抵抗

適用:

1.非編まれた織物、織物印刷、絹prntingおよび染まる機械のための乾燥機械。

2.衣服の生地の、高周波および紫外線ドライヤーのための憶病な機械。

3.食糧ベーキング、急速冷凍された機械のさまざまな熱気ドライヤーのためのコンベヤー ベルト。

4.艶をかけ、ワックスを掛けるペーパーのための給油機械プラント エンジニアリング。

メッシュ生地の技術的なデータ用紙:

Prodct 網サイズ(mm) 材料 温度(°C) 最高の幅(M) 引張強さ(N/5CM)
1 1*1 ガラス繊維 ブラウン/Balck -60/+360 4.07 1600/1500
2 4*4 ガラス繊維 Balck -60/+360 4.07 2200/1500
3 4*4 ガラス繊維 Brwon -60/+360 4.07 2100/1500
4 4*4 fiberglass+kevlar -60/+360 4.07 3300/2800
5 4*4 ガラス繊維 Brwon -60/+360 4.07 2800/1580
6 4*4 ケブラー -60/+360 4.07 3500/3300
7 4*4 ガラス繊維 -60/+360 4.07 2800/1500
8 10*10 ガラス繊維 Brwon -60/+360 4.07 1100/1000
9 0.5*1 ガラス繊維 Brwon -60/+360 4.07 2200/1500
10 2*2.5 ガラス繊維 Brwon -60/+360 4.07 2200/1500

PTFE polyester mesh fabric , PTFE polyester mesh fabric for conveyor belt / griddling cloth, made by PTFE coated 0

PTFE polyester mesh fabric , PTFE polyester mesh fabric for conveyor belt / griddling cloth, made by PTFE coated 1

PTFE polyester mesh fabric , PTFE polyester mesh fabric for conveyor belt / griddling cloth, made by PTFE coated 2
